Nowadays, many companies need to produce products in a clean room, such as large food production and processing and electronics production factory. Therefore, many companies are using clean room. The reason why clean room can be dust-free is mainly because a lot of high-tech purification equipment was installed in the clean room during decoration.

1. The air inlet system of clean room must be installed filter box, and a central purification air conditioner (the central purification air conditioner must be divided into three filter sections: primary efficiency /medium efficiency/high efficiency) with a high-efficiency air supply port at the end. It's necessary to install a purification booster box if need.

2. the return air system of clean room must be installed, including a return air outlet, a pre filter, and a middle filter return air box.

3. Enter the buffer zone before entering cleanr room. Electronic interlocks are installed on the buffer zone door, and clean storage cabinets and air fresheners are placed in the changing area. People and goods entering the clean room, must pass through the air shower, cargo shower room, and use pass box to mainly transfer small items.

4. In the clean room, vertical clean bench, laminar flow hood (FFU), clean booth (removable clean booth) and self-purifier should be installed in some places that need to reach level 10-1000. Laser dust particle counter for measuring the cleanliness of clean rooms.

5. The clean room build should be designed with observation windows to facilitate visits.

 Clean room equipment：

1、Air shower, changing room and clean room are the three basic components of the workshop purification system. The air shower is a passage in and out of the clean area. The high-speed clean air jetted out can effectively and quickly remove dust and bacteria carried by the human body. The clean room uses interlayer color steel plates to isolate the space and walls, the upper color steel ceiling is suspended, and the floor is paved with epoxy resin.

2、The most important role of air purification equipment in a clean room is to control the cleanliness, temperature and humidity of the atmosphere that products are exposed, so that products can be produced and manufactured in a good environmental space. This space is called a clean room.

3. According to the clean room management regulations, the dust-free purification level is mainly determined based on the number of particles per cubic meter of air that are greater than the classification standard. But for optical structures, a small dose may produce a very large amount, so air purification equipment is needed to build in clean room.

The above content is the purification equipment that needs to be used in the clean room. Different purification levels have different requirements for purification equipment. This mainly depends on the production needs of each enterprise.
